Small Fiber Laser Cutting Machine 1390 for Sheet Metal
Detail Information
Product Description
Small Fiber Laser Cutting Machine 1390 for Sheet Metal
Product Overview
The Small Fiber Laser Cutting Machine 1390 is a compact, high-precision cutting system designed for small-batch production, prototype shops, and educational institutions. With a 1300mm x 900mm working area, it delivers reliable performance for thin to medium sheet metal processing while fitting into limited floor space.
Key Features
- Compact Design: 1390mm working area for small workshops
- High Precision: +/-0.03mm positioning accuracy
- Fast Acceleration: Efficient cutting of thin sheets
- Rotary Axis Optional: For tube and pipe cutting
- Closed-loop Control: Stable motion and consistent cuts
- Low Maintenance: Air-cooled or water-cooled options
- User-friendly Software: Supports DXF, AI, PLT formats
- Energy Efficient: Lower power consumption
- Small Footprint: Ideal for startups and schools
- Fast Delivery: Quick setup and installation
Technical Specifications
| Feature | Specification |
|---|---|
| Laser Type | Fiber Laser |
| Working Area | 1300mm x 900mm |
| Laser Power | 1000W / 1500W / 2000W |
| Positioning Accuracy | +/-0.03mm |
| Re-positioning Accuracy | +/-0.02mm |
| Max Positioning Speed | 60m/min |
| Cutting Thickness | Up to 6mm mild steel |
| Control System | CypOne / FSCUT |
| Cooling Mode | Water Cooling |
| Power Requirement | 380V 50Hz |
Applications
- Advertising signage and lettering
- Small metal parts fabrication
- Kitchenware and hardware
- Electrical cabinet components
- Automotive small parts
- Education and training
- Prototype and R&D workshops
- Custom metal crafts
