60mm Tube Fiber Laser Cutting Machine for Round and Square Pipe
The 60mm tube fiber laser cutting machine is designed for small-diameter round and square pipe processing. Its maximum clamping capacity handles tubes up to 60mm in outer diameter, with a minimum starting from 5mm. This makes it the right entry-level tube cutter for shops that primarily process furniture tubing, handrails, gym equipment frames, and agricultural pipe components.
Unlike a large industrial tube cutter built for 200mm+ pipe, the 60mm model uses a smaller pneumatic chuck that grips thin-walled tubing without deformation. It cuts square holes, round holes, notches, and angled ends directly from CAD files.
What Can the Machine Cut?- Round pipe from 5mm to 60mm OD in carbon steel, stainless steel, aluminum, and copper.
- Square tube from 5x5mm to 50x50mm.
- Rectangular tube up to 50x30mm.
- Wall thickness up to 5mm in carbon steel at 1500W, or 4mm in stainless.
- Max tube diameter: 60mm
- Min tube diameter: 5mm
- Tube length capacity: 3000mm (standard), 6000mm optional
- Laser power: 1000W, 1500W, 2000W, 3000W
- Chuck type: Pneumatic self-centering
- Positioning accuracy: +/-0.05mm
- Supported formats: DXF, DWG
- Loading: Manual bundle loader optional
This size of tube cutter is the standard choice for:
- Furniture manufacturers cutting sofa frames, table legs, and chair tubing.
- Handrail and railing fabricators needing clean cut ends and notch joints.
- Gym and fitness equipment builders cutting workout machine frames.
- Metal service centers adding tube cutting alongside their sheet metal operations.
- Small job shops that need precise tube processing without investing in a heavy-duty 200mm+ system.
If your production is mostly small furniture tubing, handrails, and thin-walled pipe under 60mm, the 60mm machine costs significantly less and uses less floor space. If you regularly cut structural pipe, exhaust tubing, or large-diameter mechanical tubing over 100mm, you will need a 200mm or 350mm heavy-duty tube cutter with a larger chuck and longer steady rests.
