200mm Heavy Duty Tube Fiber Laser Cutting Machine for Structural Pipe
How Thick Can a 200mm Tube Laser Cut?
The 200mm heavy duty tube fiber laser cutting machine is built for structural pipe and heavy-wall tube processing. Its large hydraulic chuck grips round pipe up to 200mm OD and square tube up to 150x150mm, with wall thickness capacity up to 10mm in carbon steel at 6000W. This is the machine for steel structure fabricators, exhaust system manufacturers, and heavy equipment builders who process pipe that exceeds the capacity of small tube cutters.
The heavy duty frame is designed to handle the weight of long, thick-walled pipe. Multiple steady rests support the tube along its length to prevent deflection during cutting, which is essential when processing 6-meter structural pipe.
What Industries Use This Machine?- Steel structure and construction companies cutting H-beams, angle steel, and structural pipe.
- Exhaust and muffler fabricators cutting automotive and industrial exhaust tubing.
- Agricultural equipment manufacturers cutting thick-walled tractor and implement tubing.
- Shipbuilding and offshore fabricators cutting pipe for railings and structural supports.
- Oil and gas pipe processors needing precision cut ends and bevel preparation.
- Max round pipe diameter: 200mm
- Max square tube: 150x150mm
- Tube length: 6000mm standard
- Laser power options: 2000W, 3000W, 6000W, 12000W
- Chuck type: Hydraulic self-centering, 3-jaw
- Wall thickness at 6000W: Carbon steel up to 10mm, stainless up to 8mm
- Steady rests: Multiple, adjustable along tube length
- Positioning accuracy: +/-0.05mm
- Loading: Automatic bundle loader available
The 60mm machine is for thin-walled furniture and handrail tubing. The 200mm machine handles structural pipe and medium-wall tube up to 10mm. For pipe over 200mm OD, such as large casing pipe, column pipe, or offshore structural members, a 350mm or 500mm heavy duty tube cutter with a reinforced chuck and longer bed is required.
