Robot Fiber Laser Cleaning Machine 3000W for Rust Removal
Detail Information
Product Description
Robot Fiber Laser Cleaning Machine 3000W for Rust Removal
Product Overview
The Robot Fiber Laser Cleaning Machine 3000W integrates a high-power fiber laser source with a 6-axis robotic arm for automated, large-area rust removal, paint stripping, oxide layer cleaning, and surface preparation. Designed for heavy industrial applications, the robot arm provides flexible multi-angle operation for complex workpieces and welded structures.
Key Features
- 3000W High-Power Fiber Laser: Fast cleaning speed
- 6-Axis Robotic Arm: Flexible multi-angle operation
- Large Working Range: Handles oversized workpieces
- Automated Path Planning: Repeatable cleaning trajectories
- Non-Contact Cleaning: No substrate damage
- Environmentally Friendly: No chemicals or abrasives
- Fume Extraction Connection: Clean working environment
- Touchscreen Programming: Easy robot teaching
- Continuous Wave Operation: Stable long-duration cleaning
- Suitable for Heavy Industry: Shipbuilding, automotive, steel structures
Technical Specifications
| Feature | Specification |
|---|---|
| Laser Type | Fiber Laser |
| Laser Power | 3000W |
| Robot Axes | 6 Axis |
| Robot Reach | 2000mm standard |
| Cleaning Width | Adjustable up to 50mm |
| Cleaning Speed | Up to 30m/min |
| Cooling Mode | Water Cooling |
| Power Requirement | 380V 50Hz |
| Robot Repeatability | +/-0.05mm |
| Application | Rust, paint, oxide, coating removal |
Applications
- Shipbuilding hull and deck cleaning
- Steel structure rust removal
- Automotive frame and chassis cleaning
- Mold surface cleaning and maintenance
- Oil and gas pipeline preparation
- Railway and rolling stock maintenance
- Bridge and infrastructure maintenance
- Heavy equipment surface preparation
